This is the smoke-only member of the family: one forward-scatter chamber, one analogue channel, no heat element whatever. Gent footnote it in their own range table as the optical sensor used in the duct sensor.
Nothing here answers temperature, so a rising thermal signature alone raises no alarm at this address — worth stating plainly on any drawing where the part replaces a multisensor.
Technical data
| Label marking | O, footnoted as used in the duct sensor |
| Sensing | Forward-scatter optical smoke only |
| Analogue channels | 1 |
| Standards | EN 54-7:2000 A1:2002; A2:2006 excluded for this part |
| Baffle ring | Black (silent) |
Specifications from 4188-1073 issue 3.
Compatibility
Mounts on the standard S4-700 base. Where heat sensing is wanted in an identical footprint, S4-710 adds a thermal element on channel 2 without altering the fixing.
Installation
Inside a duct assembly, that assembly's own instructions govern sampling arrangement and airflow direction; on a ceiling it is an ordinary base fixing.
Full details: S-Quad optical sensor — installation data — 4188-1073 issue 3 · 28 pages · range table carrying the duct footnote and this single-channel entry
