The S4-710 puts forward-scatter smoke sensing and a thermal element behind a single loop address. Its label reads OH, and a healthy panel shows channels 1 and 2 against it: optical, then heat.
One viewing angle gives the panel no forward-to-backward ratio, so this head cannot separate smoke from steam or dust as its dual-angle sibling does. Fit it where the risk is straightforward.
Technical data
| Label marking | OH |
| Sensing | Forward-scatter optical smoke, plus heat |
| Analogue channels | 1 and 2 |
| Standards | EN 54-7:2000 A1:2002 and EN 54-5:2000 A1:2002; A2:2006 not applicable to this part |
| Baffle ring | Black (silent) |
Specifications from 4188-1073 issue 3.
Compatibility
Twists onto the white S4-700 base; no ingress plate is needed on a silent head, though S4-701 supplies both where IP21C matters. Being white-bodied and silent, it accepts the S4-FLUSH semi-flush kit.
Installation
Wire the base first: its programmable input/output ships as an unmonitored output, driving a remote repeat LED with no series resistor over runs to 15 metres.
Full details: S-Quad optical heat sensor — installation data — 4188-1073 issue 3 · 28 pages · channel-allocation table listing OH against 1 and 2
