The black version of the dual-optical voice sensor sounder, and the one part in this group whose baffle ring deliberately does not match its body. That ring is white, because a white ring is how an installed S-Quad declares it has sound.
Every function of the white voice head is present, reporting the same four channels upward. The difference is purely visual — and it only holds if base and ingress plate are ordered black as well.
Technical data
| Label marking | O2H/V |
| Sensing and output | Dual-angle optical, heat, voice sounder |
| Analogue channels | 1, 2, 4 and 5 |
| Body colour | Black moulding, white baffle ring |
| Sound output | 85 dBA at 1 m EN 54-3 average; +3 dB in turbo |
| Standards | EN 54-7:2000 A1:2002 A2:2006, EN 54-5:2000 A1:2002, EN 54-3:2001 A1:2002 A2:2006 |
Specifications from 4188-1073 issue 3.
Compatibility
Needs an ingress plate to satisfy the EN 54-3 mounting condition, in black: S4BK-705 over S4BK-700. The white equivalent is S4-711-V; the silent black head is S4BK-711.
Installation
No black semi-flush option exists, so plan a surface base from the outset, and check the grid: a dark assembly against a light ceiling draws the eye far more than its white counterpart.
Full details: S-Quad black voice sensor sounder — installation data — 4188-1073 issue 3 · 28 pages · black voice sensor sounder entry, four-channel allocation
